El Primero 9004

AUTOMATIC • Analog • Chronograph: Chronograph Hands: Hours, Minutes, Small Seconds Chronometer, Power Reserve Indicator

Jewels
53
Reserve
50 h
Frequency
36,000 vph (5.0 Hz)
Diameter
32.8 mm
Height
-

About this caliber

Self-winding movement with cam-actuated chronograph capable of measuring up to 1/100 of a second. The chronograph runs on its own escapement system, with a balance wheel operating at 360.000 bph. The power reserve for the chronograph is 50 minutes, and it is wound by hand. The balance for the regular timekeeping runs at 36.000 bph and is wound either by hand or through the oscilating weight. Both balance springs are made of 'carbon-matrix carbon nanotube composite'. The central hand makes one rotation every second; at 12:00 there's a power reserve indicator for the chronograph.

Technical details

Movement
AUTOMATIC
Display
Analog
Jewels
53
Power reserve
50 hours
Frequency
36,000 vph (5.0 Hz)
Hands
Chronograph: Chronograph Hands: Hours, Minutes, Small Seconds Chronometer, Power Reserve Indicator
Diameter
32.8 mm
Height
-
Parts
-
