100.0

- • Analog • Hands: Hours, Minutes, Small Seconds

Jewels
17
Reserve
42 h
Frequency
18,000 vph (2.5 Hz)
Diameter
36.4 mm
Height
-

About this caliber

Mortiz Grossmann caliber 100.0 is a hand-wound movement with a power reserve of 42 hours. It consists of 188 parts including 17 jewels, of which 3 are done in screwed gold chatons. It features a shock-resistant screw balance with Breguet overcoil shaped after G. Gerstenberger. The 2/3 plate and frame pillars are made of untreated German silver. The bridges (/plates) as well as balance and escape-wheel cocks are manually engraved, including broad horizontal Glashütte ribbing, and three-band snailing on the ratchet wheel. Other notable features include the
 screwed, raised gold chatons, the separately removable clutch winder, the modified Glashütte stopwork with controlled backlash, and the adjustment with a Grossmann micrometer screw on the cantilevered balance cock.

Technical details

Movement
-
Display
Analog
Jewels
17
Power reserve
42 hours
Frequency
18,000 vph (2.5 Hz)
Hands
Hands: Hours, Minutes, Small Seconds
Diameter
36.4 mm
Height
-
Parts
-
